YUEI skeleton caster swivel wheel 25 diameter polycarbonate wheel (red)

[Features] ● Easy-to-use casters with light starting resistance. ●Polycarbonate casters that do not stain the floor. -Wheel color variations can be used according to the application.

[Applications] ● Lightweight dolly ● Indoors such as offices ● Office supplies

[Specifications] - Allowable load (daN): 10 - Allowable load (kgf): 10.2 - Wheel diameter D (mm): 25 - Color: red - Wheel width (mm): 12 - Mounting height H (mm): 35 Mounting seat A (mm): 35 Mounting seat B (mm): 30 Mounting pitch X (mm): 28 Mounting pitch Y (mm): 23 Mounting hole diameter P (mm): 4.2 Allowable load (N ): 100

[Specification 2] ● Plate type ● Flexible type

[Material/Finish] ●Metal fittings: Steel ●Metal fitting surface treatment: trivalent unichrome plating finish ●Wheels: Polycarbonate

[Set contents/accessories]
-

[Caution] ● Safe load = allowable load per caster x number of uses x 0.8
