VICTOR Soft Jaw Forming Jig Jaw Lock JL-032 JL-125~200 Supplementary

[Features]
● Minimize consumption of soft jaws by stepless fine adjustment.
●Extremely convenient for forming soft jaws for small-diameter gripping.
●Exhibits power in processing through soft jaws.
●By reversing the mounting direction of the jaws, the processing range is expanded.

[Use]
●For soft-jaw forming jigs for 3-jaw chucks.
● Can be used for hydraulic/pneumatic chucks and scroll chucks.

【specification】
● Applicable chuck outer diameter (inch): JL-125 to 200 complement
- Pin diameter (mm): 12.0
- Outer diameter (mm): 98
- Maximum processing dimension (mm): 31
- Inner diameter (mm): 32

[Specification 2]
-

[Material/Finish]
-

[Set contents/accessories]
-

【Note】
●Maximum processing dimensions are for through processing.
