IDEC Flat Push Button Switch Red

[Features] ● Jet-proof and oil-proof type. (NECA CA4520) ● UL, CSA, CCC certified and EN standard compliant product. ●Equipped with the same contact block for all models of φ22, 25, and 30mm control UNIT to improve convenience in terms of safety and man-hours reduction. ●The IP20 contact block is protected from electric shock during work with an integrated terminal cover. ●The contact block is color-coded for easy identification by the operator.

[Use]
-

[Specifications] Action: Momentary Contact configuration: 1b Button color: Red

[Specification 2] ●Protection grade: IP65 (IEC60529) ●Panel cut size: 30mm

[Material/Finish] ●Body: Polyamide ●Operation part (lens): Polyacetal ●Terminal part: Copper ●Ring: Zinc die-cast
