TRUSCO belt sling both ends eye type 25mmX0.5m

[Features]
Moderate stretch softens the impact.
The green side (used side) and the orange side (outer side) are color-coded. (Due to the structure of the belt sling, the green side (used side) and the orange side (outer side) have different durability, so please use the green side (used side) correctly.)

[Use]
Steel materials: Transportation of surface processed steel materials such as plating and painting, steel pipes, steel plates, etc.
Machinery: Transportation of automobiles, automobile parts, and precision machinery.

【specification】
Maximum working load (t): 0.8
Total length (m): 0.5
Belt dimensions (mm) width x thickness: 25 x 12
Eye width (mm): 30
Eye length (mm): 150
Eye thickness (mm): 9
Sewing length (mm): 200
Color: Orange

[Specification 2]
JIS B 8818 standard product (some products have non-JIS standard dimensions)
JIS B 8818 standard product (G25 to G50: 1M or higher standard product, G75 to G150: 2M or higher standard product)
G25 Length less than 1m is out of JIS standard
Operating temperature: 100°C or less
Both ends eye shape

[Material/Finish]
Nylon (inner: polyester)

[Set contents/accessories]
-

【caution】
G25-05, G25-07, and G25-08 are non-JIS standard products.
Not for chemical resistance.
Since it is a textile product, there may be some errors in the dimensions. Please contact us in advance if strict length alignment is required for a set of two.
Be sure to use corner pads or other padding in places where there is a risk of damage to textile slings such as belt slings due to sharp corners or friction on the luggage.
Even if a padding is used, the sling may be damaged or cut due to sliding of the load, contact with surrounding walls or objects, pressure, etc., so please be careful of the work environment.
