JST NH connector housing 100 pieces included

[Features] ● Highly reliable leaf-shaped spring structure. ●Double-sided contact.

[Use] ●For wiring inside equipment. ● 2.5mm pitch for wire-to-board connection.

[Specifications] A (mm): 5.0 Number of poles: 3 Applicable wire range: AWG #28 to #22 B (mm): 8.2 Rated current: 3 A C (mm): 11.2 Insulation resistance: 500 MΩ ●Applicable contact: BHF-001T-0.8BS

[Specification 2] ●Rated voltage: 250V ●Operating temperature range: -25°C to +85°C (including temperature rise values) ●Withstand voltage: AC1500V/1 minute

[Material/Finish] ● Nylon 6 (UL94V-0)

[Set contents/accessories]
-

【Note】
-
