[Features] ● Uses a contact that is easy to insert and has excellent holding power. ●Compatible with ML connectors.
[Use] ●For relay connection. ● 4.5mm pitch for wire-to-wire connection.
[Specifications] A (mm): 24.6 Number of poles: 2 Applicable wire range: AWG#26 to #16, 0.13 to 1.25 mm [[squared]] B (mm): 10.3 Rated current: MAX 10A - C (mm): 5.6 - Insulation resistance: 1000 MΩ or more
[Specification 2] ● Rated voltage: MAX300V ● Operating temperature range: -25°C to +90°C (including temperature rise values) ● Withstanding voltage: AC1500V/1 minute
