JST NH connector base pin top type (100 pieces)

[Features] ● Highly reliable leaf-shaped spring structure. ●Double-sided contact.

[Use] ●For wiring inside equipment. ● 2.5mm pitch for wire-to-board connection.

[Specifications] - A (mm): 22.5 - Number of poles: 10 - Shape: Top type - Applicable wire range: AWG#28 to #22 - Rated current: 3A - Insulation resistance: 500MΩ or more

[Specification 2] ●Rated voltage: 250V ●Operating temperature range: -25°C to +85°C (including temperature rise values) ●Withstand voltage: AC1500V/1 minute

[Material/Finish] ●Brass/copper-undercoated tin plating (reflow treatment) ●Base: Nylon 66 (UL94V-0)

[Set contents/accessories]
-

【Note】
-
