Base pin top type for JST PH connector (100 pieces included)

[Features] ● Uses a highly reliable contact with a compact design. ●The post with base is a box type.

[Use] ●For wiring inside equipment. ● 2.0mm pitch for wire-to-board connection.

[Specifications] A (mm): 18.0 Number of poles: 10 Shape: top type Applicable wire range: AWG #30 to #24 B (mm): 21.9 Rated current: 2 A Insulation resistance: 1000 MΩ or more

[Specification 2] ●Rated voltage: 100V ●Operating temperature range: -25°C to +85°C (including temperature rise values) ●Withstand voltage: AC800V/1 minute

[Material/Finish] ● Base: Nylon 66 (UL94V-0) ● Brass/copper-undercoated tin plating (reflow treatment)

[Set contents/accessories]
-

【Note】
-
