FUSO Cool Dumbo SHA1-30 (flat blow for air, 1 axis, with 30cm magnet attachment)

[Features]
One-touch magnet nozzle for air.
You can freely change the spray direction.
Because it is made of a pressure-resistant bellows tube, the jet is hard to shake.

[Use]
For powerful duster, cooling, drying and draining. (Please use MAGIC CUT e-mist for spraying cutting fluid.)
For removing chips from workpieces, blowing away small press items, removing dust, etc.

【specification】
Number of nozzles: 1
Hole diameter (mm): φ3 x 1.0 slit
Nozzle length (mm): 300
Air intake: G1/4
Applicable fluid: Air
Adsorption force (N): 250
Maximum working pressure (MPa): 0.7

[Specification 2]
Pressure-resistant bellows type, freely bendable, flow control type cap
Minimum bend R=40mm
flat blow

[Material/Finish]
Flexible tube: SWM, SWC
Inner tube: copper tube
Nozzle part, etc.: Brass chrome

[Set contents/accessories]
-

【Note】
-
