Unica resin A SE type (sealed capsule type) SE-24

[Features]
Adhesive anchor with excellent earthquake resistance.
It is also suitable for application to wet base materials.
Long-term storage before construction is possible by using vinyl ester resin with high alkali resistance.

[Use]
Foundation work such as steel frames.
road construction.
tunnel construction.
Installation work for vibrating machines, etc.

【specification】
Outer diameter (mm): 25
Total length (mm): 180
Capacity ([[CM 3]]): 76.0
Capacity (ml): 76
Bolt used (deformed steel bar): M24, W1 (D25)
Drill diameter (deformed steel bar) (mm): 28.0 (32.0)
Drilling depth (mm): 220
Maximum tensile load (kN): 225.2
Long-term allowable tensile load (kN): 37.1
Short-term allowable tensile load (kN): 74.3

[Specification 2]
Rotating/Blowing type

[Material/Finish]
Main agent: vinyl ester resin

[Set contents/accessories]
-

【Note】
-
