Unica resin A SE type (sealed capsule type) SE-20

[Features]
Adhesive anchor with excellent earthquake resistance.
It is also suitable for application to wet base materials.
Long-term storage before construction is possible by using vinylester resin with high alkali resistance.

[Use]
Foundation work such as steel frames.
road construction.
tunnel construction.
Installation work for vibrating machines, etc.

【specification】
Outer diameter (mm): 21.5
Total length (mm): 175
Capacity ([[CM 3]]): 53.0
Capacity (ml): 53
Bolt used (deformed steel bar): M20, W3/4 (D19)
Drill diameter (deformed steel bar) (mm): 25.0 (25.0)
Drilling depth (mm): 180
Maximum tensile load (kN): 170.1
Long-term allowable tensile load (kN): 25.1
Short-term allowable tensile load (kN): 50.2

[Specification 2]
Rotating/Blowing type

[Material/Finish]
Main agent: vinyl ester resin

[Set contents/accessories]
-

【Note】
-
