Unica resin A SE type (sealed capsule type) SE-12

[Features]
Adhesive anchor with excellent earthquake resistance.
It is also suitable for application to wet base materials.
Long-term storage before construction is possible by using vinylester resin with high alkali resistance.

[Use]
Foundation work such as steel frames.
road construction.
tunnel construction.
Installation work for vibrating machines, etc.

【specification】
Outer diameter (mm): 12.7
Overall length (mm): 100
Capacity ([[CM 3]]): 9.8
Capacity (ml): 9.8
Bolt used (deformed steel bar): M12, W1/2 (D13)
Drill diameter (deformed steel bar) (mm): 14.0 (16.0)
Drilling depth (mm): 110
Maximum tensile load (kN): 69.7
Long-term allowable tensile load (kN): 9.2
Short-term allowable tensile load (kN): 18.5

[Specification 2]
Rotating/Blowing type

[Material/Finish]
Main agent: vinyl ester resin

[Set contents/accessories]
-

【Note】
-
