[Features]● The sleeve (ferrule) prevents wires from coming apart and contributes to quality improvement. ●We have prepared a wide variety of colors that can be color-coded by wire size. ●For connecting two electric wires.
[Applications] ● For spring connection, push-in terminal block, and various other European terminal blocks.
[Specifications] ● Wire coupling range Stranded wire ([[MM2]]): 16 ● Color: green ● Total length (mm): 38.0 ● L2 (mm): 25.0 ● D1 (mm): 8.3 ● Wire coupling range AWG: 6 ●Compatible wire: 16mm2/AWG 6
[Specification 2] ● Crimp terminal based on DIN 462228 part 4 ● Total length: 38 mm ● Conductor length: 25 mm ● Strip length: 8.3 mm ● Insulation width: 0.3 mm ● Insulation color: green
