[Features]● The sleeve (ferrule) prevents wires from coming apart and contributes to quality improvement. ●We have prepared a wide variety of colors that can be color-coded by wire size.
[Applications] ●For spring connection, push-in terminal block, and various other European terminal blocks.
[Specifications] ● Wire coupling range Stranded wire ([[MM2]]): 0.75 ● Color: White ● Overall length (mm): 18.0 ● Inner dimension (mm): 2.8 ● L2 (mm): 12.0 ● Wire coupling range AWG: 18 ●Applicable wire: 0.75mm2/AWG 18 ●Wire coupling range single wire mm: -
[Specification 2] ● Crimp terminal based on DIN 462228 part 4 ● Overall length: 18 mm ● Conductor length: 12 mm ● Strip length: 14 mm ● Insulation width: 2.8 mm ● Insulation color: White
