[Features]● The sleeve (ferrule) prevents wires from coming apart and contributes to quality improvement. ●We have prepared a wide variety of colors that can be color-coded by wire size.
[Applications] ● For spring connection, push-in terminal block, and various other European terminal blocks.
[Specifications] ● Wire coupling range Stranded wire ([[MM2]]): 2.5 ● Color: Blue ● Total length (mm): 15.0 ● Inner dimension (mm): 4.2 ● L2 (mm): 8.0 ● Wire coupling range AWG: 14 ●Applicable wire: 2.5 mm2/AWG 14 ● Wire coupling range single wire mm: -
[Specification 2] ● Crimp terminal based on DIN 462228 part 4 ● Total length: 15 mm ● Conductor length: 8 mm ● Strip length: 10 mm ● Insulation width: 4.2 mm ● Insulation color: blue
