[Features]● The sleeve (ferrule) prevents wires from coming apart and contributes to quality improvement. ●We have prepared a wide variety of colors that can be color-coded by wire size. ●For connecting two electric wires.
[Applications] ● For spring connection, push-in terminal block, and various other European terminal blocks.
[Specifications] ● Wire coupling range Stranded wire ([[MM2]]): 6 ● Color: Black ● Total length (mm): 23.0 ● L2 (mm): 12.0 ● D1 (mm): 4.5 ● Wire coupling range AWG: 10 ●Compatible wire: 6mm2/AWG 10
[Specification 2] ● Crimp terminal based on DIN 462228 part 1 ● Total length: 23 mm ● Conductor length: 12 mm ● Strip length: 4.5 mm ● Insulation width: 0.2 mm ● Insulation color: black
