[Features]● The sleeve (ferrule) prevents wires from coming apart and contributes to quality improvement. ●Available in 12 color variations that can be color-coded for each wire size.
[Applications] ● For spring connection, push-in terminal block, and various other European terminal blocks.
[Specifications] ● Wire coupling range Stranded wire ([[MM2]]): 16 ● Color: green ● Overall length (mm): 28.0 ● Inner dimension (mm): 8.8 ● L2 (mm): 18.0 ● Wire coupling range AWG: 6 ●Applicable wire: 16mm2/AWG 6●Wire coupling range single wire mm: -
[Specification 2] ● Crimp terminal based on DIN 462228 part 4 ● Total length: 28 mm ● Conductor length: 18 mm ● Strip length: 21 mm ● Insulation width: 8.8 mm ● Insulation color: green
