[Features] ●It is possible to control 3 electric dramas with 1 unit. ●Prevents forgetting to tighten screws and incomplete screw tightening. ●Counter function: count (counts the number of tightening screws, adds up or subtracts them, and displays the remaining number.) ●Channel (You can register the upper limit of screw tightening time + retightening time.) ●Sequence (A series of processes can be registered by combining channels.) Pokayoke (If you tighten up to the set number, you will be notified of the completion with an alarm sound and light.) Retightening (Retightening can be done after tightening.) Improper tightening (Insufficient tightening and wrong screws are managed by screw tightening time and notified with an alarm sound and light.) ●External signal input/output: Up to 3 SOP models can be connected.
[Use] ●To prevent forgetting to tighten screws and improve reliability at production sites such as industrial machinery, industrial electrical equipment, and automobile testing.
[Specification 2] ●Input: DC24V 300mA (Power adapter AD24-SC2 sold separately) ●Display screen: LCD 16 characters x 2 lines (5x8 dots) Signal input/output terminals: 2 input terminals (TLP785), 3 output terminals (TLP627), line output (output impedance 1 kΩ) - Registerable sequences: 16 sequences x 64 channels each ● Registerable channels: 32 channels ●Number of counts that can be registered: 1 to 99 - Count method: count up / count down (switchable) ●Auto reset time: 0.00 to 9.99 seconds -Screw tightening time: 0.01 to 9.99 seconds (upper limit time), 0.00 to 9.99 seconds (lower limit time) - Compatible models: VE-5000SOP (P), R, S, VE-6000SOP (P), SOP, R
[Material/Finish] -
[Set contents/accessories] ●Instruction manual
【Note】 ● Only lever type can be installed (cannot be used for push type). ●Tightening torque is reduced by approximately 20% when attachments are attached.
