[Features] ● Kosoku type is twice as fast as conventional models, and you can feel the improvement in work efficiency. (*Comparison with VE-5000.) ● Easy-to-use ergonomic design with a shock-absorbing gel pad for a firm grip. ●Tightening accuracy, efficiency, and maintainability are improved by adopting a slotless/brushless motor. ●Prevents erroneous adjustment with a tamper-proof sleeve.
[Use] ●For control of simultaneous use of multiple models on the assembly line, interlocking with peripheral devices, etc.
【specification】 - Output torque (N m): 0.6 to 2.5 - Total length (mm): 290 No-load rotation speed (min [[-1 power]]): 2000 - Compatible screw (mm) small screw: M3.0 to 4.0 - Bit opposite side (mm): 6.35 - Compatible screw (mm) tapping screw: 2.6 to 3.5 Power consumption (W): 150 -Power cord length (m): 2.5
[Specification 2] ●Push type Power supply: AC type -Torque adjustment ring: 16 steps x 8 scales ●PSE standard
【Note】 ● Read the instruction manual carefully and check that the wiring is correct before turning on the power. ●If the forward/reverse switch of the electric screwdriver is set to the intermediate position, the motor will remain stopped even while the start signal is being output. ●Be sure to stop the motor rotation before operating the forward/reverse switch of the electric screwdriver. ●Please note that a signal may be output when the power of the electric screwdriver is turned on or off.
