[Features] ●The grip is easy to hold with a gel pad that absorbs vibrations, making it less tiring. (ergonomic design) ●Maintenance-free, no need to replace carbon brushes. ●Prevents erroneous adjustment with a tamper-proof sleeve. ●Long-life and low-noise brushless motor.
[Use] ●For control of simultaneous use of multiple models on the assembly line, interlocking with peripheral devices, etc.
【specification】 - Output torque (N m): 0.4 to 1.8 - Total length (mm): 250 No-load rotation speed (min [[-1 power]]) strong: HI1000/LO700 No-load rotation speed (min [[-1 power]]): HI: 1000 / LO: 700 - Compatible screw (mm) small screw: M3.0 to 4.0 - Compatible screw (mm) tapping screw: 2.3 to 3.0 Power consumption (W): DC32V 55 Attached bit: D73 [[+]] 1 x 40 / [[+]] 2 x 40 1 each
[Specification 2] -Torque adjustment ring: 16 steps x 8 scales ●Push start type
【Note】 ● Read the instruction manual carefully and check that the wiring is correct before turning on the power. ● Do not use anything other than a PLC (photocoupler input) for the device connected to the signal output line. ●Do not connect the + side of the power supply directly to the signal output line. ●There will be no current limiting resistor, and the photocoupler will be damaged. ●Do not drive relays, motors, lamps, etc. directly connected to the signal output line.
