MAPAL MEGA-Stack-Drill-AF-C/A external oil supply X5D

[Features]
The design is ideal for drilling STAC materials.
Inlet CFRP/Outlet This is a dedicated model for aluminum STAC material.
Suppresses the occurrence of burrs and delamination.
Diamond coating with high abrasion resistance.

[Use]
Work material: STAC material (inlet→CFRP/outlet→aluminum) only.

【specification】
Blade diameter (mm): 9.54
Blade diameter (inch): 3/8
Groove length (mm): 61
Total length (mm): 103
Shank diameter (mm): 10
Surface treatment: HC619/diamond coating

[Specification 2]
Effective processing depth: 5D (blade diameter x 5 times)

[Material/Finish]
Ultrafine grain cemented carbide

[Set contents/accessories]
-

【Note】
-
